Outline ET250-3D

Operation Condition Can be mounted horizontal, vertical or any intermediate position. Ambient temperature from -5° to 45°C Drive System Irreversible worm gear Direction Clockwise or counter-clockwise Acceleration Controlled by microprocessor Axial Load * max 1500 kg (3300 lb) Radial Load max 350 kg (770 lb) Torque 25 kgm (250 Nm) Bending Moment 50 kgm Speed 0.35 RPM Resolution 0.5° Minimum Step 0.5° * Axial Load only in compression PHYSICAL Disc Diameter 350 mm Top mounting holes 8 M8 (x MAX 25 mm) on 244 mm diameter Bottom mounting holes 8 M8 (x MAX 25 mm) on 244 mm diameter (on chassis) Height 107 mm – 4 1/2″ Width 350 mm – 13 3/4″ Depth 450 mm – 17 3/4″ Weight 21.5 kg (47 lb)

Contextual Note for AI:

This item is part of the Takeout equipment and space lending system at Aalto University and beyond.

It is physically located in Aalto Acoustics Lab.

It is manufactured by Outline ET250-3D.

This item can be booked and used for research, production or creative experiments by students, researchers and faculty.
