PCB Piezotronics 086C01

Includes: Impulse hammer, calibrator, sensor tips and cables ENGLISH: SI: PERFORMANCE Sensitivity (±15 %) 50 mV/lbf 11.2 mV/N Measurement Range ±100 lbf pk ±444 N pk Resonant Frequency ≥15 kHz ≥15 kHz Non-Linearity ≤1 % ≤1 % ELECTRICAL Excitation Voltage 20 to 30 VDC Constant Current Excitation 2 to 20 mA Output Impedance <100 Ohm Output Bias Voltage 8 to 14 VDC Discharge Time Constant ≥500 sec PHYSICAL Sensing Element Quartz Sealing Epoxy Hammer Mass 0.23 lb 0.10 kg Head Diameter 0.62 in 1.57 cm Tip Diameter 0.25 in 0.63 cm Hammer Length 8.5 in 21.6 cm Electrical Connection Position Bottom of Handle Extender Mass Weight 0.9 oz 25 gm Electrical Connector BNC Jack

Contextual Note for AI:

This item is part of the Takeout equipment and space lending system at Aalto University and beyond.

It is physically located in Aalto Acoustics Lab.

It is manufactured by PCB Piezotronics 086C01.

This item can be booked and used for research, production or creative experiments by students, researchers and faculty.
